Airtac GTC Air Treatment Combination GTC20008LNK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20008LNK Technical Specifications
- Model: GTC20008LNK
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT3/8 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 3,500 NL/min
- Filter element: 40μm sintered bronze (5μm optional)
- Regulator accuracy: ±0.2 bar
- Lubricator capacity: 200cc (visible oil level)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR/HNBR (Viton optional)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.65 kg (empty)
- Dimensions: 220mm(H) × 160mm(W) × 110mm(D)
- Pressure gauge: 63mm dial (MPa/psi dual scale)
- Drain type: Manual float drain
- Mounting: Bracket-integrated design
Industrial-grade FRL unit combining particulate filtration (with automatic drain), precision pressure regulation, and adjustable aerosol lubrication. Features a maintenance-friendly modular design with tool-free bowl removal. The transparent bowls allow visual monitoring of filter contamination and oil level. Includes a shock-resistant pressure gauge with silicone damping fluid.
- Pneumatic production lines in automotive manufacturing
- Plastic injection molding machine air preparation
- CNC machine tool pneumatic systems
- Packaging machinery actuator control
- Robotic arm end-effector supply systems
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain minimum 50mm clearance below drain port for maintenance access.
Lubricator should be filled with ISO VG32 turbine oil (1/2 bowl capacity recommended).
| Property | Property Value |
|---|---|
| sku | GTC20008LNK |
| Port Size | PT1/4 |
