Airtac GTC Air Treatment Combination GTC20008LNW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Series Triple Unit GTC20008LNW Technical Specifications
- Model: GTC20008LNW
- Type: Modular FRL unit (Filter-Regulator-Lubricator)
- Port size: PT1/2 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow: 3000 L/min
- Filter rating: 40μm (5μm optional element available)
- Lubricator oil capacity: 180cm³
- Adjustment knob torque: ≤1.5N·m
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR/Nitrile rubber
- Temperature range: 5℃ to 60℃ (with anti-freeze kit: -20℃)
- Weight: 1.25kg (dry), 1.43kg (with oil)
- Dimensions: 165mm(H) × 100mm(W) × 85mm(D)
- Pressure gauge: Dual scale 0-1.6MPa (psi/kPa)
- Drain type: Manual float drain
Modular compressed air treatment unit combining precision filtration (with auto-drain), pressure regulation with lockable knob, and adjustable oil mist lubrication. Features dual-chamber filter bowl with impact baffle and transparent polycarbonate cover. The regulator includes over-pressure relief and zero-leakage design.
- Pneumatic tool stations in automotive assembly lines
- CNC machine air preparation systems
- Packaging machinery air line conditioning
- Industrial robot end-effector supply lines
- Plastic injection molding machine air circuits
Installation guidelines:
Mount vertically with flow arrow alignment. Maintain 50mm clearance below drain port.
Lubricator should be positioned last in the FRL sequence. Replace filter element every
6,000 operational hours or when pressure drop exceeds 0.05MPa.
| Property | Property Value |
|---|---|
| sku | GTC20008LNW |
| Port Size | PT1/4 |
