Airtac GTC Air Treatment Combination GTC20008LNWK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20008LNWK Technical Specifications
- Model: GTC20008LNWK
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Thread connection: G1/4 (BSPP)
- Filtration grade: 40μm (5μm optional with micro-filter)
- Pressure regulation range: 0.05–1.0 MPa
- Max flow rate: 2,000 NL/min
- Pressure gauge range: 0–1.6 MPa (dual scale bar/kPa)
- Drain type: Manual/auto drain conversion (float structure)
- Body material: Die-cast aluminum (anodized finish)
- Operating temperature: 5℃ to 60℃ (no freeze)
- Lubricator capacity: 200cc (transparent polycarbonate bowl)
- Mounting style: Modular stackable design
- Weight: 1.35 kg (complete unit)
- Dimensions: 160mm(W) × 145mm(H) × 95mm(D)
Industrial-grade air preparation unit combining precision filtration (with water separator), pressure regulation, and adjustable lubrication. Features quick-drain mechanism with visible contamination alert and anti-backflow design. Integrated mounting grooves allow direct connection to ISO cylinder profiles.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Automotive assembly line tooling
- Packaging machinery air circuit protection
- Food processing pneumatic controls (oil-free version available)
Maintenance note:
Replace filter element when pressure drop exceeds 0.1MPa.
Lubricator oil level should be maintained between 1/3–2/3 of bowl capacity.
Install upstream of directional control valves for optimal performance.
| Property | Property Value |
|---|---|
| sku | GTC20008LNWK |
| Port Size | PT1/4 |
