Airtac GTC Air Treatment Combination GTC20008LWK
$73.27
Regular price
$80.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GTC20008LWK
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. This product adopts the GA200 series compact PC bowl specification, retaining all GA200 series characteristics while featuring these unique advantages:
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
Maintenance tip:
Replace filter element when red ring becomes visible (approx. 5,000 operating hours).
Lubricator oil level should be maintained between 1/3 to 2/3 capacity for optimal performance.
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC20008LWK Triple Unit (FRL) Specifications
- Model: GTC20008LWK
- Type: Filter-Regulator-Lubricator (FRL) combination unit
- Port size: PT1/2" (NPT optional)
- Operating pressure range: 0.05–0.9 MPa
- Maximum flow: 2,800 L/min (ANR)
- Filter rating: 5 μm (40 μm optional element available)
- Pressure gauge: 1/8" dial type (liquid-filled)
- Lubricator oil capacity: 200 cc
- Temperature range: -20℃ to 60℃ (non-freezing)
- Weight: 1.2 kg (empty)
- Dimensions: 180mm(W) × 120mm(H) × 120mm(D)
- Body material: Anodized aluminum alloy
- Seal material: NBR (HNBR optional)
- Drain type: Manual float drain
- Pressure adjustment: Knob with lockable mechanism
Modular FRL unit with integrated pressure gauge and corrosion-resistant construction. Features dual-chamber filter bowl with visible contamination indicator and anti-drip lubricator design. The staggered port arrangement allows compact installation in confined spaces.
Typical Applications:
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automotive assembly line tool protection
- Packaging machinery air quality control
- Food processing equipment (with optional stainless steel bowl)
Maintenance tip:
Replace filter element when red ring becomes visible (approx. 5,000 operating hours).
Lubricator oil level should be maintained between 1/3 to 2/3 capacity for optimal performance.
| Property | Property Value |
|---|---|
| sku | GTC20008LWK |
| Port Size | PT1/4 |
