Airtac GTC Air Treatment Combination GTC20008SNK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20008SNK Technical Specifications
- Model: GTC20008SNK
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/2 (BSPP thread)
- Maximum pressure: 1.5 MPa
- Filtration rating: 5 μm (with auto-drain)
- Pressure regulation range: 0.05–0.85 MPa
- Lubricator capacity: 200 cm³
- Operating temperature: 2℃ to 60℃
- Body material: Aluminum alloy (anodized)
- Seal material: NBR/HNBR (optional)
- Weight: 1.2 kg (dry)
- Dimensions: 200mm(L) × 135mm(W) × 160mm(H)
- Flow capacity: 2000 NL/min (ANR)
- Condensate discharge: Semi-automatic float drain
- Pressure gauge: 40mm dial (MPa scale)
Modular FRL unit combining 3-stage air preparation with corrosion-resistant construction. Features a transparent polycarbonate bowl with metal guard, precision pressure regulation knob with lock mechanism, and adjustable oil drip rate (2-10 drops/min). Designed for industrial environments requiring stable air quality.
- Pneumatic production line main air supply
- Packaging machinery air preparation systems
- Food processing pneumatic controls (NSF compliant version available)
- Automotive assembly tool air supply
- CNC machine pneumatic circuits
Installation protocol:
Install in sequence (filter→regulator→lubricator) with minimum 300mm straight inlet piping.
Mount vertically using bracket slots (M6 mounting holes). Maintain ambient temperature above dew point.
Replace filter element every 4,000 operating hours.
| Property | Property Value |
|---|---|
| sku | GTC20008SNK |
| Port Size | PT1/4 |
