Airtac GTC Air Treatment Combination GTC20008SNWK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20008SNWK Technical Specifications
- Model: GTC20008SNWK (Filter-Regulator-Lubricator Combination)
- Thread size: 1/4" NPT (BSPP/BSPT optional)
- Operating pressure: 0.05-0.9 MPa
- Max flow rate: 2000 L/min
- Filtration grade: 5 μm (with auto-drain)
- Adjustable pressure range: 0.05-0.85 MPa
- Lubricator oil capacity: 80 cm³
- Weight: 1.2 kg (with mounting bracket)
- Dimensions: 180mm(L) × 85mm(W) × 120mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -20℃ to 60℃ (non-freezing conditions)
- Pressure gauge: 1/8" NPT interface, 0-1.0 MPa range
Modular FRL unit featuring a maintenance-friendly twist-lock bowl design with impact-resistant PC cover. The integrated bypass valve maintains airflow during filter replacement. Includes a visual pressure gauge with ±2% accuracy and tamper-proof adjustment knob. Compatible with ISO 8573-1 air quality standards.
- Pneumatic tool stations in automotive assembly lines
- CNC machine air preparation systems
- Packaging machinery compressed air conditioning
- Industrial robot end-effector supply lines
- Plastic injection molding air circuits
Installation protocol:
Mount vertically within 5° tolerance. Maintain 50mm clearance below bowl for drainage.
Lubricator should be positioned last in the FRL sequence. Prime with ISO VG32 oil,
adjusting drip rate to 1-2 drops/m³ airflow.
| Property | Property Value |
|---|---|
| sku | GTC20008SNWK |
| Port Size | PT1/4 |
