Airtac GTFC Air Filter Regulator Combination GTFC20006L
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006L Filter Regulator Unit Technical Details
- Model: GTFC20006L (F.R.L Combination Unit)
- Type: 2-stage combination (40μm filter + precision pressure regulator)
- Port size: PT1/4 (BSPP) with auto drain
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow capacity: 3,500 NL/min
- Filter element: 40μm sintered stainless steel (replaceable)
- Regulator accuracy: ±0.07 MPa
- Pressure gauge: 1/8" NPT interface (0-1.6 MPa range)
- Body material: Die-cast aluminum alloy (anodized surface)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Weight: 1.25 kg (with bracket)
- Dimensions: 160mm(H) × 100mm(W) × 85mm(D)
- Mounting: Panel bracket with M5 screw slots
Modular air preparation unit combining high-efficiency particulate filtration (ISO 8573-1 Class 4) with precision pressure stabilization. Features manual bypass lever for emergency operation and shock-resistant polycarbonate bowl guard. Designed for continuous duty cycles with 500,000+ maintenance-free operations.
- Pneumatic production line air conditioning
- CNC machine tool pneumatic systems
- Packaging machinery pressure stabilization
- Automated assembly line tooling
- Semiconductor manufacturing clean air supply
Maintenance protocol:
Replace filter element every 5,000 operating hours or when pressure drop exceeds 0.1 MPa.
Lubricator requires ISO VG32 turbine oil if optional oiler kit is installed.
| Property | Property Value |
|---|---|
| sku | GTFC20006L |
| Port Size | PT1/8 |
