Airtac GTFC Air Filter Regulator Combination GTFC20006LNK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006LNK Filter Regulator Lubricator (FRL) Unit Specifications
- Model: GTFC20006LNK
- Type: Compact 2-stage combination unit (Filter + Regulator)
- Port size: PT1/2 (NPT1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 3,500 L/min (ANR)
- Filter rating: 5μm (40μm optional element available)
- Pressure gauge: 1/8" BSP dial type (0-1.6 MPa range)
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: NBR/PU compound
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.85 kg
- Dimensions: 195mm(H) × 145mm(W) × 105mm(D)
- Mounting: Bracket slot 45mm (compatible with ISO 4414)
Modular FRL unit featuring automatic drain function with visible bowl design. The dual-stage configuration combines 5μm particulate filtration with precision pressure regulation (0.05-1.0 MPa). Includes shock-resistant polycarbonate bowl with metal guard and anti-rotation bracket. Meets ISO 8573-1 class 4 air quality standards.
- Pneumatic tool stations in automotive assembly
- Packaging line air preparation systems
- CNC machine compressed air conditioning
- Food processing equipment (oil-free version available)
- Semiconductor manufacturing cleanrooms
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Drain bowl requires weekly manual purging in high-humidity environments.
Use 2-point bracket mounting with M5 screws (torque 3.5-4.0 N·m).
| Property | Property Value |
|---|---|
| sku | GTFC20006LNK |
| Port Size | PT1/8 |
