Airtac GTFC Air Filter Regulator Combination GTFC20006LW
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series Filter Regulator Lubricator (FRL) Unit - GTFC20006LW Specifications
- Model: GTFC20006LW
- Type: 2-stage combination unit (Filter + Regulator)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 3,500 L/min
- Filtration grade: 5 μm (with auto-drain)
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Body material: Die-cast aluminum (anodized finish)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.82 kg (dry, without accessories)
- Dimensions: 178mm(H) × 98mm(W) × 115mm(D)
- Drain type: Semi-automatic float drain
- Mounting: Bracket slot (accepts 22-26mm panel thickness)
- Protection rating: IP42 (splash-resistant design)
Industrial-grade air preparation unit combining particulate filtration and precision pressure regulation. Features a transparent polycarbonate bowl with sediment visibility window and anti-blowout safety ring. The corrosion-resistant construction includes a metal shield over critical components for workshop environments.
- Pneumatic production line main air conditioning
- CNC machine tool pneumatic systems
- Automated assembly line pressure stabilization
- Packaging machinery air supply management
- Industrial robot end-effector controls
Maintenance note:
Replace filter element every 6,000 operational hours or when pressure drop exceeds 0.1 MPa.
Bowl torque specification: 3.5-4.0 N·m during reassembly.
| Property | Property Value |
|---|---|
| sku | GTFC20006LW |
| Port Size | PT1/8 |
