Airtac GTFC Air Filter Regulator Combination GTFC20006SN
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006SN Filter Regulator Lubricator (FRL) Unit Specifications
- Model: GTFC20006SN
- Type: Compact inline filter-regulator-lubricator combo
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.15–1.0 MPa
- Filtration rating: 5 μm (40μm optional element)
- Pressure regulation range: 0.05–0.85 MPa
- Max flow capacity: 3,500 L/min (ANR)
- Oil reservoir capacity: 130 cc
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.2 kg (with oil)
- Dimensions: 200mm(L) × 100mm(W) × 150mm(H)
- Protection rating: IP42
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Drain type: Manual float drain
Triple-function pneumatic conditioning unit combining 5μm particulate filtration, precision pressure regulation, and adjustable oil mist lubrication. Features a corrosion-resistant aluminum body with transparent polycarbonate bowl for visual monitoring. Equipped with a locking pressure adjustment knob and tamper-proof cap.
- Production line pneumatic tool stations
- Packaging machinery air preparation
- Automated assembly line actuators
- CNC machine tool pneumatic systems
- Industrial robotics end-effector controls
Installation guidelines:
Mount vertically with arrow direction matching airflow (filter first, regulator middle, lubricator last).
Maintain 50mm clearance below bowl for drainage. Replace filter element every 2,000 operational hours
or when pressure drop exceeds 0.1 MPa. Use ISO VG32 turbine oil for lubrication.
| Property | Property Value |
|---|---|
| sku | GTFC20006SN |
| Port Size | PT1/8 |
