Airtac GTFC Air Filter Regulator Combination GTFC20006SNK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006SNK Filter Regulator Combination Unit Specifications
- Model: GTFC20006SNK
- Type: 2-in-1 unit (Filter + Regulator)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.85 MPa
- Max flow rate: 2000 L/min
- Filtration grade: 5 μm (40μm optional)
- Pressure gauge: 1/8" dial type (0-1.0 MPa scale)
- Body material: Aluminum alloy (anodized)
- Bowl material: Polycarbonate (PC)
- Seal material: NBR
- Temperature range: -5℃ to 60℃
- Drain type: Manual drain with semi-auto lever
- Protection rating: IP42
- Weight: 0.85 kg
- Dimensions: 180mm(L) × 130mm(W) × 130mm(H)
Modular air preparation unit combining precision filtration and pressure regulation. Features a visible bowl with anti-static coating to prevent dust adhesion. The integrated bypass design maintains airflow during maintenance. Requires 15-30% less space than conventional modular assemblies.
- Pneumatic tool stations in automotive assembly
- Packaging line air supply systems
- Semiconductor manufacturing equipment
- Food processing pneumatic controls
- Medical device air pressure management
Installation protocol:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Perform weekly manual draining in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GTFC20006SNK |
| Port Size | PT1/8 |
