Airtac GTFC Air Filter Regulator Combination GTFC20006SW
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006SW FRL Combination Unit Specifications
- Model: GTFC20006SW
- Type: Filter-Regulator-Lubricator (Compact Series)
- Filter rating: 5 μm (with auto-drain)
- Pressure regulation range: 0.05–0.9 MPa
- Max flow rate: 2,200 L/min (ANR)
- Port size: G1/4 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa
- Temperature range: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (anodized)
- Weight: 1.25 kg (with oil)
- Dimensions: 195mm(W) × 135mm(H) × 90mm(D)
- Lubricator capacity: 180 cm³
- Oil viscosity range: ISO VG32–VG68
- Protection rating: IP42 (standard)
All-in-one pneumatic conditioning unit featuring triple-stage filtration (40/5/0.01 μm) and precision pressure regulation with ±0.02 MPa accuracy. The integrated micromist lubricator includes a sight dome with anti-blowout shield. Designed for harsh industrial environments with optional bowl protector (sold separately).
- CNC machine pneumatic systems
- Automated assembly line tooling
- Plastic injection molding machines
- Industrial robot end-effector control
- Packaging machinery air preparation
Installation note:
Mount vertically with filter bowl downward. Maintain 50mm clearance below drain port.
Lubricator oil level should be kept between 1/3 to 2/3 capacity. Replace filter element
when pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GTFC20006SW |
| Port Size | PT1/8 |
