Airtac GTFC Air Filter Regulator Combination GTFC20008L
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20008L Filter Regulator Lubricator (FRL) Unit Specifications
- Model: GTFC20008L
- Type: Compact inline filter-regulator-lubricator combo
- Port size: PT1/4 (BSPP)
- Operating pressure range: 0.15–1.0 MPa
- Maximum flow: 3,000 L/min (ANR)
- Filter rating: 5 μm (40μm optional mesh available)
- Adjustment knob torque: 0.3–0.6 N·m
- Pressure gauge: 40mm dial, ±2.5% accuracy
- Weight: 820g (with bracket)
- Dimensions: 158mm(H) × 95mm(W) × 62mm(D)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual or semi-auto (optional)
- Seal material: HNBR with anti-aging coating
- Body material: Die-cast aluminum (anodized)
Modular triple-function unit combining precision filtration (with water separation), pressure regulation, and oil mist lubrication in a space-saving design. Features a tamper-proof adjustment knob with lockable setting and dual-scale pressure gauge (MPa/psi). The transparent polycarbonate bowl allows visual contamination monitoring.
- Pneumatic tool stations in automotive assembly lines
- CNC machine air preparation systems
- Packaging machinery air line conditioning
- Robotic actuator supply lines
- Industrial painting systems requiring lubricated air
Maintenance tip:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
Always depressurize before bowl removal. For vertical installation, maintain minimum 50mm
clearance below drain port for service access.
| Property | Property Value |
|---|---|
| sku | GTFC20008L |
| Port Size | PT1/4 |
