Airtac GTFC Air Filter Regulator Combination GTFC20008LN
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20008LN FRL Combination Unit Specifications
- Model: GTFC20008LN
- Type: Filter Regulator Lubricator (FRL) Combination
- Port size: PT1/2 (BSPP thread)
- Maximum pressure: 1.5 MPa
- Operating pressure range: 0.05–1.0 MPa
- Filtration grade: 40μm (with auto-drain)
- Flow capacity: 3,500 Nl/min
- Lubricator oil capacity: 200cc
- Adjustment knob rotation: 270° with lockable design
- Weight: 2.8 kg (complete unit)
- Dimensions: 220mm(H) × 150mm(W) × 105mm(D)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (with lubricant), -5℃ to 80℃ (without lubricant)
- Pressure gauge: Dual scale (MPa/psi) 0-1.6 MPa range
- Mounting: Bracket-integrated design with M5 mounting holes
Industrial-grade triple-function unit combining precision filtration, pressure regulation, and air lubrication. Features a transparent polycarbonate bowl with metal guard and anti-static coating. The regulator includes a tamper-proof adjustment lock and zero-pressure reset safety mechanism.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated assembly line actuators
- Food packaging machinery (oil-free version available)
- Plastic injection molding air circuits
Maintenance note:
Drain bowl requires weekly inspection in humid environments.
Use ISO VG32 turbine oil for lubrication. Avoid mounting in direct
vibration zones (max. vibration tolerance 4.9m/s²).
| Property | Property Value |
|---|---|
| sku | GTFC20008LN |
| Port Size | PT1/4 |
