Airtac GTFC Air Filter Regulator Combination GTFC20008LNW
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series F.R.L Unit GTFC20008LNW Technical Specifications
- Model: GTFC20008LNW (Filter Regulator Combination)
- Port size: PT1/2 (G1/2 equivalent)
- Maximum flow: 3,500 L/min
- Operating pressure range: 0.15–1.0 MPa
- Filtering grade: 5 μm (40μm optional)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6 MPa scale)
- Drain type: Manual float drain
- Body material: Die-cast aluminum (anodized finish)
- Bowl material: Polycarbonate (PC)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.25 kg (with bracket)
- Dimensions: 198mm(H) × 102mm(W) × 98mm(D)
- Mounting: Bracket slot (compatible with 35mm/45mm rail)
Professional-grade air preparation unit combining precision filtration and pressure regulation. Features impact-resistant PC bowl with 180° rotation capability for flexible installation. The dual-chamber design ensures stable output pressure during demand fluctuations. Includes anti-clogging sintered filter element and silicone-coated diaphragm for extended service life.
- Centralized pneumatic system distribution lines
- CNC machine tool air supply conditioning
- Automated assembly line pressure management
- Packaging machinery air circuit protection
- Plastic injection molding machine auxiliary systems
Maintenance protocol:
Replace filter element every 4,000 operational hours or when differential pressure exceeds 0.1MPa.
Lubricator oil viscosity should match ISO VG32 standards if added downstream.
- Install upstream of pneumatic components requiring clean, dry air
- Maintain vertical orientation (±15° tolerance)
- Allow minimum 50mm clearance below bowl for drainage access
- Use PTFE tape on male threads only
| Property | Property Value |
|---|---|
| sku | GTFC20008LNW |
| Port Size | PT1/4 |
