Airtac GTFC Air Filter Regulator Combination GTFC20008LWK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series Filter Regulator Lubricator (FRL) Unit GTFC20008LWK Specifications
- Model: GTFC20008LWK (LWK variant with locking pressure knob)
- Type: 2-stage combination unit (40μm filter + pressure regulator)
- Port size: PT3/8 (G3/8) with dual female threads
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 3,500 Nl/min (ANR)
- Filter element: 40μm sintered stainless steel (replaceable)
- Pressure gauge: 1/8" BSPT dial gauge (0-1.6 MPa range)
- Adjustment knob: Lockable rotary knob with ±2% regulation accuracy
- Drain type: Manual push-button drain with anti-splash shield
- Body material: Die-cast aluminum with epoxy coating
- Seal material: NBR (Nitrile) standard / optional FKM
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Weight: 1.25 kg (dry, without lubricant)
- Dimensions: 182mm(H) × 100mm(W) × 82mm(D)
Modular FRL unit combining high-efficiency particulate filtration (ISO 8573-1 Class 4) with precision pressure regulation. Features a tamper-proof adjustment mechanism and visual pressure feedback via integrated gauge. The vertical stack design minimizes footprint while allowing drip bowl access. Compatible with ISO 7-1 mounting brackets.
- Pneumatic tool air preparation stations
- Packaging line actuator control systems
- CNC machine tool air curtain protection
- Semiconductor handling robotics
- Food processing pneumatic circuits (optional FDA-grade seals)
Maintenance protocol:
Replace filter element every 5,000 operating hours or when differential pressure exceeds 0.1MPa.
Lubricator function requires separate installation (not included in base model).
| Property | Property Value |
|---|---|
| sku | GTFC20008LWK |
| Port Size | PT1/4 |
