Airtac GTFC Air Filter Regulator Combination GTFC20008S
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series Twin Unit GTFC20008S Technical Specifications
- Model: GTFC20008S
- Type: Filter regulator lubricator (FRL) combination unit
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow: 3,500 L/min (ANR)
- Filter rating: 40μm (5μm optional element available)
- Pressure gauge: 1/8" BSP dial type (0-1.6 MPa scale)
- Lubricator oil capacity: 180 cm³
- Weight: 2.8 kg (with oil)
- Dimensions: 250mm(H) × 150mm(W) × 100mm(D)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR/FKM optional
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Drain type: Manual float drain
- Pressure adjustment: Knob with lockable mechanism
Modular FRL unit combining 40μm filtration, precision pressure regulation, and adjustable lubrication. Features dual-stage pressure stabilization with over-pressure safety lock and visual contamination indicator. Equipped with anti-vibration mounting brackets and tamper-proof adjustment controls.
- Centralized pneumatic system pretreatment
- Plastic injection molding machine air lines
- Automated assembly line tooling stations
- CNC machine tool pneumatic circuits
- Food packaging equipment (FDA-grade oil option)
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
Lubricator refill interval: 8 weeks under continuous operation. Always depressurize before servicing.
| Property | Property Value |
|---|---|
| sku | GTFC20008S |
| Port Size | PT1/4 |
