Airtac GTFC Air Filter Regulator Combination GTFC20008SK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20008SK FRL Combination Unit Specifications
- Model: GTFC20008SK
- Type: Twin unit (Filter Regulator with pressure gauge)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 3,500 L/min (ANR)
- Filtration rating: 40μm (1st stage), 5μm (2nd stage)
- Adjustable pressure range: 0.05–0.85 MPa
- Weight: 1.8 kg (dry)
- Dimensions: 195mm(L) × 135mm(W) × 155mm(H)
- Body material: Die-cast aluminum (filter bowl: polycarbonate)
- Temperature range: 5℃ to 60℃ (non-freezing)
- Drain type: Manual/auto drain optional
- Pressure gauge range: 0–1.6 MPa
- Thread torque: 25–30 N·m installation torque
Modular air treatment unit combining precision filtration and pressure regulation, featuring dual-stage particle separation and visible bowl design. The corrosion-resistant structure includes a shatterproof transparent bowl with safety guard, optimized for industrial air line conditioning. Requires 10-15% oversize in upstream piping for peak performance.
- Pneumatic tool air supply systems
- CNC machine pneumatic circuits
- Packaging line actuator control
- Food processing air preparation
- Robotic arm pneumatic systems
Maintenance tip:
Replace filter element when pressure drop exceeds 0.1MPa.
Bowl cleaning recommended every 500 operational hours in humid environments.
| Property | Property Value |
|---|---|
| sku | GTFC20008SK |
| Port Size | PT1/4 |
