Airtac GV Slow Start Valve GV20006C1BI
$65.10
Regular price
$72.60
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GV20006C1BI
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The GV Slow Start Valve is designed to ensure safe pressure build-up in pneumatic systems, providing critical safety protection. When the valve's input port (P) is connected to the compressed air supply and the coil is energized, the 3-port 2-position valve opens. This allows a controlled airflow through the throttle valve to output port (A), enabling gradual system pressurization. The valve fully opens when output pressure reaches 50% of input pressure, achieving maximum flow capacity. Upon de-energization, port P closes while the check valve redirects residual air from the system to exhaust port (R) for rapid depressurization, resetting the system to zero pressure to ensure operational safety.
Category: Slow Start Valves | Brand: AirTAC | Series: GV
Installation protocol:
Mount vertically (±15° tolerance) with exhaust ports downward. Use 5μm filter + 20-40μm lubricator upstream.
For AC coils, maintain voltage within ±10% to prevent humming. Allow 15mm clearance around exhaust silencers.
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow Start Valve GV20006C1BI Technical Details
- Full model code: GV20006C1BI (includes manual override)
- Valve type: 5/2-way pilot-operated with slow exhaust function
- Port configuration: G1/4 (ISO standard thread)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V 50/60Hz, AC220V 50Hz
- Flow capacity: Cv=1.2 (Kv=1.4) @7bar
- Response time: ≤100ms (actuation/deactivation)
- Seal material: Heat-resistant NBR (Nitrile) compound
- Ambient temperature: -5℃ to 60℃ (operating fluid: 0-50℃)
- Coil insulation class: F (155℃)
- Power consumption: 2.5W (AC), 2.8W (DC)
- Body material: Aluminum alloy (anodized surface)
- Protection rating: IP67 (dust/water resistant)
- Weight: 450g ±5% (including coil)
- Dimensions: 100mm(L) × 50mm(W) × 75mm(H)
- Port positions: P (pressure), A/B (actuators), R/S (exhaust)
The GV20006C1BI features progressive flow control through precision-machined throttling channels, minimizing actuator shock during startup. Its double-seal structure with wear-compensating guides ensures leak-free operation beyond 10 million cycles. The integrated surge suppression design prevents water hammer effects in long tubing systems.
Industrial Applications:
- Pneumatic cylinder soft-start sequences in assembly robots
- Packaging line clamp pressure ramping systems
- Medical bed actuator speed modulation
- Semiconductor wafer handling vacuum/pressure balancing
- Elevator door mechanism cushioning control
Installation protocol:
Mount vertically (±15° tolerance) with exhaust ports downward. Use 5μm filter + 20-40μm lubricator upstream.
For AC coils, maintain voltage within ±10% to prevent humming. Allow 15mm clearance around exhaust silencers.
Cycle optimization:
Achieve maximum lifespan by maintaining 0.3-0.5MPa lubrication pressure and annual seal kit replacement
(P/N: GV-SK20006). Use AirTAC VG-68 hydraulic oil for lubrication if required.
| Property | Property Value |
|---|---|
| sku | GV20006C1BI |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | DC24V |
