Airtac GV Slow Start Valve GV20008C1E
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow Start Valve GV20008C1E Specifications
- Model: GV20008C1E
- Type: 3/2-way normally closed with slow start function
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (DC12V), 2.2W (DC24V)
- Response time: 0.5–8 sec adjustable
- Flow rate: 850 NL/min (at 0.5 MPa)
- Weight: 280g ±5%
- Dimensions: 68mm(L) × 42mm(W) × 36mm(H)
- Seal material: Heat-resistant FKM (Fluorocarbon Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (both inlet/outlet)
Precision slow-start pneumatic valve featuring adjustable ramp-up time for smooth actuator movement. The GV20008C1E incorporates a shock-absorbing structure and anti-vibration design, with gold-plated pins for enhanced corrosion resistance. Requires 5μm filtered dry air (dew point -20℃ below ambient).
- Precision assembly line cushioning systems
- Medical bed/power chair actuator control
- Packaging machine gripper force regulation
- Semiconductor handling robotic arms
- Elevator door safety mechanisms
Installation note:
Mount in vibration-free environments with ≥15mm clearance below for adjustment access.
Use M3×8 screws (1.2-1.5N·m torque). Perform weekly manual cycling during standby periods.
Critical notice:
Do NOT use silicone-based lubricants - compatible only with phosphate ester-based oils.
Maximum 100,000 cycles between maintenance at rated pressure.
| Property | Property Value |
|---|---|
| sku | GV20008C1E |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/4 |
| Bracket Code | With Bracket |
| Coil Voltage | AC24V |
