Airtac GV Slow Start Valve GV20008C1F
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow-Start Speed Control Valve GV20008C1F Technical Details
- Model: GV20008C1F (GV series with manual override)
- Type: 3-port 2-position normally closed (with speed control)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Flow capacity: 650 NL/min (ANR)
- Voltage options: DC24V (±10%), AC110V/220V (±10% 50/60Hz)
- Power consumption: DC: 3.2W / AC: 4.5VA
- Response time: 20ms (ON)/15ms (OFF) at 0.5MPa
- Weight: 385g ±5g (including solenoid coil)
- Dimensions: 53mm(W) × 53mm(H) × 86mm(L)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -5℃ to 80℃ (no ice formation)
- Protection rating: IP67 (dustproof & temporary immersion)
- Cycle life: ≥5 million operations
- Adjustment range: 0.05–1.2 seconds full stroke time (both directions)
Precision speed control valve featuring dual adjustable needle valves for independent regulation of inlet/outlet airflow rates. The GV20008C1F incorporates a "slow-start" mechanism to prevent mechanical shock in pneumatic systems, with visible flow adjustment knobs and emergency manual override. Brass body with electroless nickel plating ensures corrosion resistance in humid environments.
- Automated assembly line actuator synchronization
- Packaging machine clamp force control
- Die-casting machine mold cushioning
- Semiconductor handling robot end-effectors
- Elevator door safety mechanism damping
Installation guidelines:
Mount in vibration-free position using M4 mounting screws (max torque 1.2N·m).
Adjust flow rates under system pressure using 2mm hex key.
Requires 5μm filtration with automatic drain.
Lubricated air (ISO VG32) recommended for extended seal life.
| Property | Property Value |
|---|---|
| sku | GV20008C1F |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/4 |
| Bracket Code | With Bracket |
| Coil Voltage | DC12V |
