Airtac GV Slow Start Valve GV20008C3A
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow-Start Valve GV20008C3A Technical Specifications
- Model: GV20008C3A
- Type: 5/3-way closed center, slow-start pneumatic valve
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Coil insulation class: Class F (155℃)
- Response time: ≤80ms (with integrated flow control)
- Flow rate: 850 NL/min (Cv=1.2)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Weight: 720g ±3% (including mounting accessories)
- Dimensions: 105mm(L) × 54mm(W) × 78mm(H)
- Protection grade: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (under rated conditions)
Precision-engineered slow-start valve with progressive flow control, featuring a dual-coil heat dissipation design for continuous operation. The built-in adjustable flow regulator (0.2-8 L/min) enables smooth actuator acceleration, reducing mechanical shock in sensitive systems. Compatible with ISO 8573-1 Class 3 compressed air.
- Assembly line robotic gripper pressure sequencing
- Injection molding machine clamp force modulation
- Elevator door safety mechanisms
- Food processing pneumatic actuators requiring gradual motion
- Lithium battery production environment (anti-spark design)
Installation protocol:
Mount horizontally with arrow aligned to airflow direction.
Use copper-free lubricated air (ISO VG32 equivalent).
Requires 15mm front/rear clearance for maintenance access.
| Property | Property Value |
|---|---|
| sku | GV20008C3A |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/4 |
| Bracket Code | With Bracket |
| Coil Voltage | AC220V |
