Airtac GV Slow Start Valve GV20008F1B
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow Start Valve GV20008F1B Technical Specifications
- Model: GV20008F1B
- Type: 3-position 5-way pilot-operated slow start valve
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–0.9 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 380g ±5%
- Dimensions: 68mm(L) × 45mm(W) × 84mm(H)
- Flow capacity: 1800 NL/min (ANR)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -10℃ to 80℃ (no freezing)
- Response time: 30-150ms adjustable start-up delay
- Protection rating: IP67 (dustproof & temporary immersion)
- Compliance: CE, RoHS, REACH
Precision-engineered slow activation valve featuring progressive pressure buildup technology. The GV20008F1B incorporates anti-vibration brass core construction with a shock-absorbing spool design, minimizing mechanical stress during operation. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality standards.
- Precision assembly line clamping mechanisms
- Injection molding machine mold protection systems
- Automotive test bench actuators
- Glass handling vacuum cup arrays
- Semiconductor wafer transport systems
Installation protocol:
Mount horizontally with arrow aligned to airflow direction. Allow 15mm
clearance on lateral sides for heat dissipation. Use flexible tubing
connections to prevent torque transmission. Perform weekly manual
override tests for maintenance validation.
| Property | Property Value |
|---|---|
| sku | GV20008F1B |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/4 |
| Bracket Code | With Bracket |
| Coil Voltage | DC24V |
