Airtac GVF Vacuum Filter GVF20006JW
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF20006JW Vacuum Filter Technical Details
- Model: GVF20006JW (Vacuum Series)
- Type: Compact inline vacuum filter with automatic drain
- Port size: 1/4" NPT (G1/4 optional)
- Filtration grade: 40 μm (multi-layer stainless mesh)
- Max flow capacity: 350 L/min @ 0.6 MPa
- Operating pressure: -100 kPa to 1.0 MPa
- Body material: Anodized aluminum alloy
- Bowl material: Transparent PC (polycarbonate)
- Temperature range: -5℃ to 60℃
- Protection rating: IP40 (dust protected)
- Weight: 280g ±5% (dry condition)
- Dimensions: 78mm(H) × 52mm(W) × 52mm(D)
High-efficiency coalescing filter designed for vacuum line protection, featuring dual-stage filtration with moisture separation. The transparent bowl allows visual debris monitoring, while the auto-drain function prevents liquid accumulation. Compatible with ISO 8573-1 air quality standards.
- Vacuum pick-and-place systems in SMT assembly
- Medical suction device filtration
- Food packaging vacuum generators
- Semiconductor wafer handling equipment
- Laboratory vacuum chambers
Maintenance tip:
Replace filter element every 2,000 operating hours or when bowl reaches 80% contamination.
Install vertically with arrow mark facing downstream. Use thread seal tape on male ports.
| Property | Property Value |
|---|---|
| sku | GVF20006JW |
| Port Size | PT1/8 |
