Airtac GVF Vacuum Filter GVF20008W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF20008W Vacuum Filter Technical Details
- Model: GVF20008W
- Type: Multi-stage vacuum filtration unit
- Port size: PT3/8 (G3/8 optional)
- Filtration grade: 5μm (primary) + 0.3μm (secondary)
- Max flow rate: 1,200 L/min
- Operating pressure: -100 kPa to 0.8 MPa
- Body material: Anodized aluminum alloy
- Bowl material: Impact-resistant polycarbonate
- Temperature range: -10℃ to 60℃
- Drain type: Manual drain with anti-splash shield
- Weight: 1.2 kg (with mounting bracket)
- Dimensions: 120mm(L) × 80mm(W) × 180mm(H)
- Filter efficiency: 99.9% @ 0.3μm particles
- Pressure loss: ≤0.02 MPa @ rated flow
- Installation orientation: Vertical or horizontal
High-efficiency dual-stage vacuum filter with transparent debris collection bowl, designed for critical vacuum line protection. Features chemical-resistant seals (FKM/Viton) and quick-release bowl mechanism for maintenance. Integrated mounting lugs allow direct pipeline or panel installation.
- Vacuum pick-and-place systems in SMT assembly
- Medical suction device inlet filtration
- Packaging machine vacuum gripper protection
- Lithium battery production cleanrooms
- Automated optical inspection (AOI) equipment
Maintenance protocol:
Replace primary filter element every 2,000 operating hours or when bowl contamination reaches 80% visibility threshold.
Use only isopropyl alcohol for bowl cleaning to prevent material degradation.
| Property | Property Value |
|---|---|
| sku | GVF20008W |
| Port Size | PT1/4 |
