Airtac GVF Vacuum Filter GVF200C06
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GVF200C06
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Unique spiral flow channel design induces controlled swirling motion in passing gases, enabling efficient liquid separation and effective solid particle filtration;
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02MPa.
Always install downstream of lubricator (when used) with minimum 300mm tubing distance from vacuum generator.
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200C06 Vacuum Filter Technical Specifications
- Model: GVF200C06 (Vacuum Generator Series)
- Filtration grade: 40μm stainless steel mesh
- Flow capacity: 200L/min (at 0.5MPa)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: -100kPa to 0.8MPa
- Maximum vacuum pressure: -92kPa (at 0.5MPa supply)
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM)
- Temperature range: -20℃ to 60℃
- Weight: 320g ±5g
- Dimensions: 82mm(L) × 58mm(W) × 43mm(H)
- Drain type: Manual drain valve with anti-splash cap
- Mounting orientation: Vertical installation recommended
High-efficiency coalescing filter designed for vacuum systems, featuring dual-stage filtration with mechanical separation and mesh coalescence. The corrosion-resistant construction ensures stable performance in humid environments. Integrated silencer reduces exhaust noise to ≤65dB(A).
Typical Applications:
- Vacuum gripping systems for material handling robots
- PCB manufacturing vacuum chambers
- Medical device assembly with clean air requirements
- Automated packaging line suction cups
- 3D printer bed adhesion systems
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02MPa.
Always install downstream of lubricator (when used) with minimum 300mm tubing distance from vacuum generator.
Configuration:
- Install between vacuum generator and suction cup
- Ensure arrow direction matches airflow
- Use PTFE tape on male threads
- Perform vacuum leak test after installation
| Property | Property Value |
|---|---|
| sku | GVF200C06 |
| Port Size | PT1/8 |
