Airtac GVF Vacuum Filter GVF200C06JW
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200C06JW Vacuum Filter Technical Specifications
- Model: GVF200C06JW
- Type: Inline vacuum filter with auto-drain
- Port size: PT1/8 (G1/8 optional)
- Filtration grade: 40μm (5μm optional with JW filter element)
- Max flow capacity: 200 L/min
- Operating pressure: -100kPa to 1.0MPa
- Body material: Anodized aluminum alloy
- Seal material: HNBR rubber (-20℃ to 120℃)
- Weight: 320g ±5%
- Dimensions: 98mm(L) × φ54mm (cylindrical body)
- Bowl capacity: 15ml
- Pressure drop: ≤0.02MPa @ 500L/min
- Thread engagement: 12mm minimum
- Installation orientation: Vertical or horizontal
High-efficiency coalescing filter designed for vacuum line protection, featuring a transparent polycarbonate bowl with debris visibility. The JW variant includes a hydrophobic filter element that traps particulates while allowing moisture drainage. Includes built-in silencer for exhaust air noise reduction (72dB(A) max).
- Vacuum pick-and-place systems in PCB handling
- Medical suction device inlet filtration
- Packaging machine vacuum grippers
- Lithium battery production cleanrooms
- 3D printer vacuum bed systems
Maintenance protocol:
Replace filter element every 2,000 operational hours or when bowl contamination reaches 80% visibility.
Use neutral detergent for bowl cleaning - avoid acetone. Always depressurize before servicing.
| Property | Property Value |
|---|---|
| sku | GVF200C06JW |
| Port Size | PT1/8 |
