Airtac GVF Vacuum Filter GVF200C06W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200C06W Vacuum Filter Technical Specifications
- Model: GVF200C06W
- Type: Vacuum filter with auto-drain
- Filtration grade: 5μm (microns)
- Flow capacity: 200 L/min (at 0.5MPa)
- Port size: 1/4" NPT (BSPP thread optional)
- Operating pressure: -100kPa to 0 (vacuum side)
- Max vacuum pressure: -98kPa
- Body material: Anodized aluminum alloy
- Filter element: Stainless steel sintered mesh
- Drain type: Manual/auto drain valve (optional)
- Weight: 520g ±10g
- Dimensions: 82mm(L) × 65mm(W) × 128mm(H)
- Temperature range: -20℃ to 60℃
- Moisture separation efficiency: ≥95%
- Installation orientation: Vertical recommended
High-efficiency vacuum line filter with corrosion-resistant construction, designed for critical vacuum applications requiring dry, particle-free airflow. Features dual-stage filtration with mechanical separation and mesh filtration. The bowl design allows visual contamination inspection without disassembly.
- Vacuum gripping systems in pick-and-place robots
- Medical suction equipment filtration
- Semiconductor wafer handling systems
- Printing machine paper feed mechanisms
- Food packaging vacuum chambers
Maintenance note:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02MPa.
Always depressurize system before servicing. Use silicone-free sealant on threads.
| Property | Property Value |
|---|---|
| sku | GVF200C06W |
| Port Size | PT1/8 |
