Airtac GVF Vacuum Filter GVF200N06W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200N06W Vacuum Filter Technical Details
- Model: GVF200N06W
- Type: Inline vacuum filter with automatic drain
- Filtration grade: 40μm (mesh filter element)
- Body material: Anodized aluminum alloy
- Seal material: NBR + Fluororubber composite
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: -100kPa to 0.8MPa
- Max flow rate: 200 L/min
- Temperature range: -10℃ to 60℃
- Weight: 280g ±5g
- Dimensions: 76mm(L) × 50mm(W) × 98mm(H)
- Drain type: Float-operated automatic discharge
- Protection rating: IP54 (dust/water resistant)
- Maintenance cycle: 3,000hrs (standard environment)
High-efficiency vacuum line protector featuring dual-stage filtration with cyclone separation and mesh capture. The corrosion-resistant housing incorporates a visible contamination window with 0-100% scale. Integrated silencer reduces exhaust noise to ≤65dB. Compatible with vacuum pumps up to 3HP.
- PCB handling vacuum gripper systems
- Automated packaging machine suction units
- Medical device manufacturing cleanrooms
- Glass panel CNC machining centers
- Semiconductor wafer handling robots
Installation protocol:
Mount vertically within 1.5m of vacuum source. Replace filter element when red indicator reaches 80% scale.
Weekly manual drain recommended for high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GVF200N06W |
| Port Size | PT1/8 |
