Airtac GVF Vacuum Filter GVF200N08J
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200N08J Vacuum Filter Technical Specifications
- Model: GVF200N08J
- Type: Inline vacuum filter with auto-drain
- Filtration grade: 40μm (98% efficiency at 0.3μm particles)
- Maximum flow rate: 200 L/min (at 0.6MPa)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.05–0.95 MPa
- Weight: 320g ±5g (including mounting bracket)
- Dimensions: 78mm(L) × 54mm(W) × 98mm(H)
- Body material: Anodized aluminum alloy (A6063-T5)
- Filter element: Sintered stainless steel (SUS304)
- Seal material: Fluororubber (FKM)
- Temperature range: -10℃ to 80℃ (non-condensing)
- Drain type: Manual/auto dual-mode float drain
- Bowl capacity: 15ml
- Pressure drop: ≤0.02MPa at rated flow
High-efficiency vacuum line filter designed for critical pneumatic systems, featuring triple-stage filtration with cyclone separation, mesh screening, and depth filtration. The corrosion-resistant construction includes a visible sediment bowl with splash guard. The 360° rotatable bracket enables flexible installation in confined spaces.
- Vacuum gripping systems in packaging machinery
- Contamination-sensitive semiconductor handling equipment
- Medical device manufacturing cleanrooms
- Automated PCB assembly lines
- Food processing vacuum conveyors
Installation note:
Mount vertically with arrow direction matching airflow. Service every 500 operational hours
or when sediment reaches 80% bowl capacity. Use only AirTAC GVF-FE40 replacement elements.
| Property | Property Value |
|---|---|
| sku | GVF200N08J |
| Port Size | PT1/4 |
