Airtac GVF Vacuum Filter GVF30008
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF30008 Vacuum Filter Technical Details
- Model: GVF30008
- Type: Inline vacuum filter with auto-drain
- Body material: Anodized aluminum alloy (A6063)
- Port size: PT1/4 (G1/4 optional)
- Filtering precision: 5 μm (multi-layer sintered stainless steel element)
- Max flow rate: 300 L/min @ 0.6 MPa
- Operating pressure: -100 kPa to 1.0 MPa
- Temperature range: -10℃ to 60℃ (non-freezing)
- Weight: 215 g ±5g
- Dimensions: 62mm(L) × 42mm(W) × 78mm(H)
- Drain type: Manual/auto hybrid with debris collector
- Seal material: Fluororubber (FKM)
- Protection rating: IP54 (dust and splash resistant)
High-efficiency coalescing filter designed for vacuum line protection, featuring dual-stage filtration with cyclonic pre-separation. The corrosion-resistant construction and transparent bowl allow visual contamination monitoring. Optimized for systems requiring both vacuum and positive pressure protection.
- Vacuum pick-and-place systems in SMT assembly
- Medical suction device filtration
- Food packaging machine vacuum lines
- Semiconductor wafer handling equipment
- 3D printer vacuum bed systems
Maintenance tip:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02 MPa.
Always install vertically with arrow mark facing downstream. Clean bowl monthly using
non-corrosive solvents (IPA recommended).
| Property | Property Value |
|---|---|
| sku | GVF30008 |
| Port Size | PT1/4 |
