Airtac GVF Vacuum Filter GVF30008J
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF30008J Vacuum Filter Technical Specifications
- Model: GVF30008J (GVF Series)
- Port size: PT1/4 (G1/4 equivalent)
- Filtration grade: 5 μm (98% efficiency at 0.3 μm particles)
- Maximum flow rate: 300 L/min (at 0.6 MPa)
- Operating pressure: 0.1–0.8 MPa
- Body material: Anodized aluminum alloy
- Filter cup: Transparent polycarbonate with anti-shatter coating
- Seal material: Oil-resistant NBR
- Temperature range: -20℃ to 60℃
- Weight: 320 g ±5% (including mounting hardware)
- Dimensions: 58mm(D) × 85mm(H) (excluding bracket)
- Drain type: Manual push-button condensate discharge
- Bypass valve: Integrated pressure relief (auto-reopen at 0.02 MPa)
- Certification: RoHS compliant, ISO 8573-1:2010 Class 4
High-efficiency coalescing filter with visual contamination indicator, designed for vacuum pump protection and precision pneumatic systems. Features dual-stage filtration with hydrophobic media that separates liquid aerosols and solid particulates. The blue-tinted bowl allows quick inspection without UV degradation risk.
- Vacuum gripping systems in pick-and-place robots
- Medical device manufacturing cleanrooms
- Semiconductor wafer handling equipment
- CNC machine vacuum chucks
- Pharmaceutical packaging lines
Installation protocol:
Mount vertically within 1.5m of vacuum source. Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05 MPa. Use thread sealant on male ports (tapered threads only).
Critical note:
Do not use with phosphate ester-based lubricants. Maximum allowable humidity: 80% RH non-condensing. Always depressurize system before servicing.
| Property | Property Value |
|---|---|
| sku | GVF30008J |
| Port Size | PT1/4 |
