Airtac GVF Vacuum Filter GVF30008JW
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF Vacuum Filter GVF30008JW Technical Specifications
- Model: GVF30008JW
- Type: Inline vacuum filter with auto-drain
- Port size: PT1/4 (NPT1/4 optional)
- Filtration grade: 5 μm (multi-layer stainless mesh)
- Max flow rate: 200 L/min
- Operating pressure: 0.05–0.8 MPa
- Vacuum level: -100 kPa to 0 kPa
- Body material: Anodized aluminum alloy
- Filter element: SS316 sintered mesh
- Seal material: HNBR rubber (-40℃ to 120℃)
- Weight: 320 g ±5g
- Dimensions: 98mm(L) × 45mm(Ø) × 132mm(H) (including brackets)
- Drain type: Float-operated automatic
- Burst pressure: 1.5 MPa
- Thread torque limit: 15 N·m max
High-efficiency coalescing filter designed for vacuum line protection, featuring three-stage filtration (cyclonic separation, sintered mesh, and drainage barrier). The anti-corrosion aluminum housing includes integrated mounting lugs for 25mm rail installation. Automatic drain discharges accumulated liquids without breaking vacuum.
- Vacuum gripping systems in pick-and-place robots
- Medical suction equipment filtration
- PCB handling vacuum generators
- Packaging machine vacuum conveyors
- Glass processing vacuum chucks
Maintenance protocol:
Install vertically with drain port downward. Replace filter element every 3,000 operating hours or when pressure drop exceeds 0.02 MPa. Use AirTAC VF-3 filter oil for element cleaning.
| Property | Property Value |
|---|---|
| sku | GVF30008JW |
| Port Size | PT1/4 |
