Airtac HD4V Solenoid Valve HD4V110-X0
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110-X0 Solenoid Valve Technical Specifications
- Model: HD4V110-X0
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/2 (G1/2 equivalent)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 2000 L/min (ANR, at 0.5 MPa)
- Response time: ≤25 ms (excitation), ≤35 ms (de-excitation)
- Seal material: Heat-resistant NBR (Nitrile), optional FKM available
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 100℃)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 1.25 kg (2.76 lbs)
- Dimensions: 125mm(L) × 55mm(W) × 85mm(H)
- Port thread depth: 12mm (minimum engagement)
- Coil insulation class: Class F (155℃)
High-flow solenoid valve with precision-machined aluminum body and hardened stainless steel spool. Designed for heavy-duty pneumatic systems requiring rapid cycling and reliable operation in harsh environments. Features dual-chamber design for reduced pressure loss and integrated surge suppression for extended coil life. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Plastic injection molding machine clamp systems
- Automotive tire assembly line actuators
- Steel mill pneumatic cylinder control
- High-speed packaging machinery
- Paper pressurization systems
- Foundry equipment air control
Installation guidelines:
Mount in vibration-free location using M5 mounting screws (torque ≤1.2N·m).
Maintain ≥30cm clearance from high-frequency inverters. Lubricate with ISO VG32
turbine oil if operated below -5℃. Replace seals every 5 million cycles in
high-temperature applications.
| Property | Property Value |
|---|---|
| sku | HD4V110-X0 |
| Standard Voltage | DC24V |
