Airtac HD4V Solenoid Valve HD4V110AI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110AI High-Performance Solenoid Valve Technical Details
- Model: HD4V110AI
- Valve type: 5/2-way single solenoid (monostable)
- Port configuration: G1/4 (ISO standard)
- Operation mode: Internal pilot operated
- Pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Flow capacity: CV 3.2 (Kv 2.7) @ 0.5MPa
- Response time: ≤30ms (exhaust to actuation)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Fluid temperature: 0–60℃
- Protection class: IP67 (dust-tight & protected against temporary immersion)
- Weight: 1.25 kg (2.76 lbs)
- Dimensions: 160mm(L) × 50mm(W) × 80mm(H) (6.3"×2.0"×3.15")
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with optimized spool geometry for fast cycle operations. Features corrosion-resistant aluminum alloy body with hard anodized treatment. Equipped with manual override and LED status indicator. Compatible with ISO 15407-1 standard subplates. Requires 5μm filtration (40μm for emergency use).
- High-speed packaging machinery sequencing
- Plastic injection molding machine clamp control
- Automated assembly line actuators
- Textile machinery pneumatic circuits
- Semiconductor handling robots
- Die casting machine ejection systems
Installation guidelines:
Mount on vibration-damped surfaces (max. 1G vibration). Maintain minimum 20mm clearance for coil heat dissipation.
Use copper-free anti-seize compound on threaded ports. Perform monthly manual cycling if used intermittently.
Critical note:
Not compatible with phosphate ester fluids. Always install downstream pressure regulator when using gas media.
Maximum allowable leakage: 50 cm³/min @ 0.5MPa.
| Property | Property Value |
|---|---|
| sku | HD4V110AI |
| Standard Voltage | AC220V |
