Airtac HD4V Solenoid Valve HD4V110B
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110B Solenoid Valve Technical Specifications
- Model: HD4V110B
- Type: 5/2-way single solenoid pilot-operated (spring return)
- Port size: PT1/4" (G1/4" optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V/24V ±10%, AC110V/220V ±10% (50/60Hz)
- Weight: 0.62 kg ±3% (with connector)
- Dimensions: 98mm(L) × 54mm(W) × 52.5mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Power consumption: 4.8W (AC), 4.5W (DC)
- Flow capacity: Cv 1.8 (Kv 2.06) @ 0.5MPa
- Response time: ≤30ms (open/close cycle)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port thread depth: 12mm (4-turns engagement recommended)
The HD4V110B features a robust aluminum alloy body with brass core components, optimized for high-cycle industrial applications. Its dual-chamber pilot design ensures reliable switching even under pressure fluctuations. The valve incorporates surge protection circuitry and a manual override button for system debugging. Requires 5μm filtered compressed air with lubricator (ISO 8573-1:2010 Class 4.4.3).
- High-speed packaging machinery cylinder control
- Injection molding machine clamp unit sequencing
- Automated assembly line positioning systems
- CNC machine tool chuck actuators
- Plastic extrusion equipment pressure regulation
Installation guidelines:
Mount horizontally with coil upward. Maintain ≥15mm clearance around valve for heat dissipation.
Use Loctite 545 thread sealant on ports. Cycle test 3x after installation.
- Manifold base: MPA-L4V
- Connector: A-6H (IP67 rated)
- Mounting bracket: HD4V-MB2
| Property | Property Value |
|---|---|
| sku | HD4V110B |
| Standard Voltage | DC24V |
