Airtac HD4V Solenoid Valve HD4V110BI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110BI Solenoid Valve Technical Specifications
- Model: HD4V110BI
- Series: HD4V (4V series high-flow variant)
- Valve type: 5/2-way, double solenoid (with manual override)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Voltage tolerance: ±10% (Standard options: DC12V/24V, AC110V/220V 50/60Hz)
- Response time: ≤50ms (at 0.5MPa)
- Flow coefficient (Cv): 2.8 (at 0.5MPa)
- Seal material: Heat-resistant NBR (HNBR), FKM available for special orders
- Ambient temperature: -5℃ to 60℃ (with anti-freeze kit: -20℃)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Weight: ~700g (including connectors)
- Dimensions: 120mm(L) × 55mm(W) × 78mm(H)
- Port thread depth: 12mm (minimum engagement)
High-performance directional control valve designed for demanding pneumatic systems. Features dual-coil configuration for precise position holding and LED status indicators. The aluminum alloy body with hard anodizing ensures corrosion resistance in humid environments. Compatible with ISO 15407-1 standards, requires 5μm filtered air with oil mist lubrication recommended.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC machine tool pneumatic circuits
- Food processing pneumatic controls (food-grade version available)
- Automotive tire assembly equipment
Installation guidelines:
Mount in vibration-free location using M5 mounting screws (torque ≤1.2N·m).
Maintain minimum 15mm clearance around exhaust ports.
Perform monthly manual cycling during standby periods.
| Property | Property Value |
|---|---|
| sku | HD4V110BI |
| Standard Voltage | DC24V |
