Airtac HD4V Solenoid Valve HD4V110BI-AM
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110BI-AM Solenoid Valve Technical Specifications
- Model: HD4V110BI-AM
- Type: 4V series 5/2-way monostable (double solenoid optional)
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Coil insulation class: Class F (155℃)
- Weight: 450g ±5% (including coil)
- Dimensions: 76mm(L) × 42mm(W) × 64mm(H)
- Seal materials: HNBR/Nitrile compound (standard), optional FKM/Viton
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow characteristics: CV=2.4 (at 0.5MPa), Kvs=2.7m³/h
- Protection class: IP67 (coil), IP40 (valve body)
- Manual override: Paddle-type emergency actuator
High-flow directional control valve engineered for demanding industrial automation scenarios. Features dual-chamber sealing technology with hardened stainless steel spool for 2 million+ cycle durability. The low-hysteresis coil design ensures stable operation in voltage-fluctuating environments. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Pneumatic press clamping/unclamping systems
- Automated assembly line indexing mechanisms
- Plastic injection molding machine actuators
- CNC tool changer positioning systems
- Foundry equipment dust purge circuits
Installation protocol:
Mount horizontally with actuator facing downward. Maintain minimum
50mm clearance below valve for maintenance access. Use anti-vibration
brackets when installed on mobile platforms. Perform monthly lubrication
via built-in grease nipple (Molykote 33M recommended).
| Property | Property Value |
|---|---|
| sku | HD4V110BI-AM |
| Standard Voltage | DC24V |
