Airtac HD4V Solenoid Valve HD4V110C
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110C 5/2-Way Solenoid Valve Technical Specifications
- Model: HD4V110C
- Type: 5/2-way single solenoid pilot-operated
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Weight: 750g ±5% (excluding accessories)
- Dimensions: 100mm(L) × 42mm(W) × 85mm(H)
- Seal material: NBR (standard), optional Viton for high temp
- Temperature range: -5℃ to 60℃ (NBR), -5℃ to 120℃ (Viton)
- Flow capacity: Cv=0.7 (at 7 bar)
- Response time: ≤20ms (exhaust to pilot)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Max operating frequency: 5Hz (with 50% duty cycle)
High-flow directional control valve featuring aluminum alloy body with hard anodized treatment for enhanced corrosion resistance. The dual-pressure sealed spool design ensures stable operation in vibration-prone environments. Integrated manual override allows mechanical actuation during maintenance. Requires 5μm filtered/dried compressed air (ISO 8573-1:2010 Class 3.4.2).
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping/unclamping mechanisms in CNC machining centers
- Actuation control for robotic end-effectors
- Plastic injection molding machine valve gates
- Automotive tire assembly systems
Installation guidelines:
Mount with M5 screws (recommended torque 2.0N·m). Maintain ≥20mm clearance
below valve for exhaust flow. Use anti-vibration washers in mobile equipment.
Lubricate seals with ISO VG32 turbine oil if operated below -5℃.
| Property | Property Value |
|---|---|
| sku | HD4V110C |
| Standard Voltage | AC 110V |
