Airtac HD4V Solenoid Valve HD4V110E
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110E 5/2-Way Solenoid Valve Technical Specifications
- Model: HD4V110E (HD4V series)
- Valve type: 5/2-way monostable (single solenoid)
- Port configuration: 5 ports (P, A, B, R, S) / 2 positions
- Port size: G1/4 (BSPP thread) with optional NPT1/4
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 1000 L/min (ANR) at 0.5 MPa
- Voltage variants: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (-5℃ to 80℃) optional FKM available
- Body material: Aluminum alloy (anodized)
- Weight: 380g ±5% (without connector)
- Dimensions: 73mm(L) × 40mm(W) × 60mm(H)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Built-in mechanical override button
- Power consumption: 1.6W (DC), 2.2VA (AC)
High-flow proportional solenoid valve with ISO 5599-1 interface standardization. Features optimized pilot mechanism for reduced air consumption and zero-pressure start capability. The E-type variant includes LED status indicator and surge protection circuitry. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Plastic injection molding machine clamp controls
- Automated assembly line actuator sequencing
- Textile machinery cylinder positioning systems
- CNC tool changers and palletizers
- Food processing vacuum/pressure regulation
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (max torque 2.5N·m).
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Lubricate using ISO VG32 turbine oil if operated in continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | HD4V110E |
| Standard Voltage | AC24V |
