Airtac HD4V Solenoid Valve HD4V110EI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110EI Solenoid Valve Technical Specifications
- Model: HD4V110EI
- Type: 4-way, 5-port direct acting (monostable)
- Port size: G1/2 (ISO228/1 standard)
- Thread type: Rc1/2 (metric/imperial optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Proof pressure: 1.5 MPa
- Voltage tolerance: ±10% (24VDC/110VAC/220VAC 50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 4.5W (DC) / 5.5VA (AC)
- Flow capacity: 1,100 l/min (ANR) at 0.5MPa
- Response time: ≤15ms (open/close cycle)
- Seal material: HNBR (Hydrogenated Nitrile) for oil resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Weight: 1.65 kg ±3%
- Dimensions: 122mm(L) × 72mm(W) × 104mm(H)
- Mounting: ISO 5599/1 standard interface
High-flow solenoid valve with optimized spool structure for stable switching under vibration conditions. Features copper-free aluminum alloy body with hard anodizing treatment, compatible with ISO VG32 hydraulic oil environments. Includes manual override and position indicator. Requires 5μm filtration (40μm for emergency use).
- Plastic injection molding machine hydraulic circuits
- Automated assembly line clamping mechanisms
- CNC machine tool coolant control systems
- Material handling equipment actuators
- Food processing pneumatic conveying
Installation requirements:
Mount with vibration-damping brackets in high-frequency operation scenarios.
Maintain minimum 50mm clearance below valve for heat dissipation.
Lubricate seals with ISO VG32 oil every 2 million cycles.
| Property | Property Value |
|---|---|
| sku | HD4V110EI |
| Standard Voltage | AC24V |
