Airtac HD4V Solenoid Valve HD4V110F
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110F High-Performance Solenoid Valve Technical Details
- Model: HD4V110F (ISO 5599-1 compliant)
- Type: 5/2-way double solenoid operated (universal type)
- Port size: G1/8 (ISO parallel thread) / 7/16"-20 UNF optional
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (with coil and connector)
- Dimensions: 105mm(L) × 50mm(W) × 76mm(H) (excluding fittings)
- Seal materials: HNBR main seals, FKM wipers (oil & heat resistant)
- Fluid temperature: -10℃ to 80℃ (non-freezing conditions)
- Ambient temperature: -5℃ to 60℃ (with derating above 40℃)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤35ms (at 0.5MPa)
- Protection class: IP67 (coil), IP40 (valve body)
- Porting pattern: 5 ports (1: pressure, 2: exhaust, 3/5: actuators)
Industrial-grade pneumatic valve featuring high flow capacity (Cv=1.8) with zero-pressure differential operation. Enhanced copper-free aluminum alloy body with hard anodizing resists chemical corrosion. Integrated surge suppression diodes protect against voltage spikes. Manual override included for emergency operation.
- High-cycle automation: Plastic injection molding EJECTOR systems
- Robotic welding cell clamping mechanisms
- Bottle capping/palletizing equipment
- CNC machine tool chuck control
- High-humidity environments: Food processing pneumatics
Critical notes:
Requires 5μm filtration (40μm for emergency use). Lubricated air (ISO VG32) extends service life.
Mount in vibration <5G acceleration. Allow 15mm clearance below for condensate drainage.
| Property | Property Value |
|---|---|
| sku | HD4V110F |
| Standard Voltage | DC12V |
