Airtac HD4V Solenoid Valve HD4V110FI
$29.06
Regular price
$36.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HD4V110FI
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The valve set consists of three separate ordering codes for the solenoid valve, base plate, and blanking plate. These components must be ordered individually, with "assembled" clearly specified during the ordering process.
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
Mounting guidelines:
Install with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance above valve for heat dissipation.
Use Loctite 542 on port threads for permanent installations.
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110FI High-Performance Solenoid Valve Technical Details
- Model: HD4V110FI (4V series, 5-port configuration)
- Valve type: 5/2-way, double solenoid operated
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤50ms (exhaust to output)
- Flow capacity: 1600 l/min (Cv=2.2 at 0.5MPa)
- Weight: 580g ±5% (without fittings)
- Dimensions: 120mm(L) × 50mm(W) × 80mm(H) (excluding connectors)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature tolerance: -5℃ to 80℃ (non-freezing operation)
- Power consumption: 2.5W (DC models), 4.5VA (AC models)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade pneumatic valve featuring twin-coil latching control and metal-sealed spool assembly. Engineered for high-cycle applications with 10 million+ operation lifespan. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5μm particles, -20℃ dew point).
Implementation Scenarios:
- Plastic injection molding machine clamp control
- Automated assembly line positioning actuators
- Textile machinery cylinder sequencing
- Semiconductor handling equipment vacuum/pressure switching
- Beverage canning system pneumatic circuits
Mounting guidelines:
Install with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance above valve for heat dissipation.
Use Loctite 542 on port threads for permanent installations.
| Property | Property Value |
|---|---|
| sku | HD4V110FI |
| Standard Voltage | DC12V |
