Airtac HD4V Solenoid Valve HD4V120A
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120A Solenoid Valve Technical Specifications
- Model: HD4V120A
- Valve type: 5/2-way monostable (solenoid pilot operated)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.15-1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Coil insulation class: Class F (155℃)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Flow capacity: 1200 NL/min (Cv=2.15)
- Seal material: Heat-resistant NBR (Nitrile)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 1.3 kg ±2%
- Dimensions: 121mm(L) × 54mm(W) × 70mm(H)
- Port thread depth: 12mm (minimum engagement)
- Expected service life: ≥30 million cycles (under rated conditions)
High-flow industrial solenoid valve featuring dual-pressure operation capability and manual override. The HD4V series utilizes a metal-sealed spool structure with wear compensation, optimized for high cycle rates in dirty environments. Requires 5μm filtered/dried air (ISO 8573-1:2010 class 4.4.3) with oil mist lubrication recommended.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery air circuit switching
- CNC tool changers and pallet systems
- Foundry equipment pneumatic actuators
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance around exhaust ports for heat dissipation.
Use copper-free anti-seize compound on threads. Cycle valve 3-5 times
manually after long-term storage before power activation.
| Property | Property Value |
|---|---|
| sku | HD4V120A |
| Standard Voltage | AC220V |
