Airtac HD4V Solenoid Valve HD4V120BI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120BI 4V Series Solenoid Valve Specifications
- Model: HD4V120BI
- Type: 5-port 2-position single solenoid (monostable)
- Port size: G1/2 (ISO228 standard)
- Operating pressure: 0.15–0.8 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.65kg ±3%
- Dimensions: 126mm(L) × 52mm(W) × 61mm(H)
- Flow capacity: 1200 l/min (Cv=1.4)
- Seal material: Oil-resistant NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: ≤2.8W (DC24V), ≤3.5VA (AC)
- Response time: ≤20ms (open), ≤30ms (close)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Lubrication: Non-required (factory pre-lubricated)
- Mounting orientation: Any direction (horizontal/vertical)
High-flow directional control valve designed for industrial automation systems requiring rapid cycling. Features reinforced brass body with anodized aluminum solenoid assembly for corrosion resistance. The pilot-operated design ensures reliable switching under variable pressure conditions. Requires 5μm filtered compressed air with max 1% lubricant oil content (ISO8573-1 Class 4).
- Packaging machinery sequence control
- Injection molding machine cylinder actuation
- Pneumatic punching press systems
- Automotive assembly line tooling
- CNC machine tool clamping devices
- Material handling conveyor systems
Installation Guidelines:
- Install silencers on exhaust ports to reduce noise (recommended PSE530 series)
- Maintain 50mm clearance around coil for heat dissipation
- Use thread sealant on male ports (PTFE tape not recommended)
- Ground solenoid coil separately when using AC voltage
| Property | Property Value |
|---|---|
| sku | HD4V120BI |
| Standard Voltage | DC24V |
