Airtac HD4V Solenoid Valve HD4V120C
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120C Solenoid Valve Specifications
- Model: HD4V120C
- Type: 5/2-way single solenoid controlled (monostable)
- Port size: G1/2 (ISO228/1 standard)
- Operating pressure: 0.1–1.0 MPa
- Max flow rate: 2000 L/min (ANR)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Power consumption: 2.5W (DC) / 5.5VA (AC)
- Response time: ≤20ms (open), ≤15ms (close)
- Weight: 900g ±3% (including coil)
- Dimensions: 122mm(L) × 52mm(W) × 76mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Max cycling frequency: 5Hz (with lubrication)
High-flow industrial solenoid valve with reinforced aluminum alloy body and corrosion-resistant plating. Designed for heavy-duty pneumatic systems requiring rapid cycling and precise directional control. Features a manual override button for emergency operation and built-in surge suppression circuit. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Pneumatic punching machines
- Injection molding equipment clamp control
- Automated assembly line actuators
- Foundry air cylinder sequencing
- Textile machinery air flow control
Installation note:
Mount in vibration-free environment using M5 mounting screws (not included).
Maintain 15mm clearance below valve for maintenance access. Lubricate with ISO VG32
turbine oil if used in high-cycling (>3Hz) applications. Avoid angular piping connections
exceeding 15° from port axis.
| Property | Property Value |
|---|---|
| sku | HD4V120C |
| Standard Voltage | AC 110V |
