Airtac HD4V Solenoid Valve HD4V120CI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120CI High-Power Solenoid Valve Technical Details
- Model: HD4V120CI
- Type: 4V-series 5/3-way (center closed position)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1,200 l/min (Cv=1.8 at 0.5MPa)
- Weight: 1.25 kg (2.76 lbs)
- Dimensions: 152mm(L) × 82mm(W) × 83mm(H)
- Seal material: High-grade NBR (Nitrile) with FKM (Fluorocarbon) optional
- Temperature range: -5℃ to 80℃ (operating fluid), -20℃ to 60℃ (ambient)
- Power consumption: 4.8W (DC24V), 5.5VA (AC)
- Response time: ≤50ms (actuation), ≤70ms (release)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 15mm (minimum engagement)
Heavy-duty industrial solenoid valve engineered for high-flow pneumatic systems requiring precise directional control. Features triple-coil protection against overvoltage/overcurrent, manual override capability, and stainless steel plunger for 1M+ cycle durability. Compatible with ISO 8573-1:2010 Class 3 compressed air (oil content ≤5mg/m³).
- Injection molding machine clamp mechanisms
- Automated assembly line actuators
- Pressurized material handling systems
- CNC machine tool clamping units
- Foundry equipment pneumatic circuits
Installation protocol:
Mount horizontally with arrow aligned to flow direction. Install upstream
40μm filter + 5-10μm lubricator (ISO VG32 oil recommended). Perform
monthly manual cycling during standby periods exceeding 30 days.
| Property | Property Value |
|---|---|
| sku | HD4V120CI |
| Standard Voltage | AC 110V |
