Airtac HD4V Solenoid Valve HD4V120E
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120E High-Flow Solenoid Valve Specifications
- Model: HD4V120E
- Type: 5/2-way double solenoid operated (universal design)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 1,600 L/min (ANR) | Cv value: 16
- Weight: 520g (including connectors)
- Dimensions: 150mm(L) × 60mm(W) × 60mm(H)
- Seal material: Heat-resistant NBR (up to 80℃ intermittent)
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Power consumption: 2.8W (DC) / 4.5VA (AC)
- Response time: ≤20ms (at 0.5MPa)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-performance industrial solenoid valve featuring dual-coil latching design for energy efficiency. The HD4V120E's large flow path geometry reduces pressure drop by 30% compared to standard valves, making it ideal for rapid cylinder cycling. Includes manual override and LED status indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
- Automotive welding fixture controls
- Bulk material handling systems
- Plastic injection molding machines
- Food processing pneumatic circuits
- Palletizer actuator clusters
Installation notes:1. Mount with vibration damping pads in high-cycle applications (>5Hz)
2. Maintain 50mm clearance above valve for heat dissipation
3. Use PTFE tape on ports with clockwise wrapping (do not obstruct flow paths)
4. Verify voltage tolerance matches power supply fluctuations
| Property | Property Value |
|---|---|
| sku | HD4V120E |
| Standard Voltage | AC24V |
