Airtac HD4V Solenoid Valve HD4V120EI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120EI High-Performance Solenoid Valve Technical Details
- Model: HD4V120EI
- Valve type: 5/2-way monostable (single solenoid)
- Port configuration: G1/2" (BSPP thread)
- Effective sectional area: 28mm² (Cv=1.5)
- Operating pressure range: 0.1-1.0 MPa (14.5-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal materials: HNBR/NBR (nitrile) with PTFE piston ring
- Ambient temperature: -5℃ to 60℃ (with 0℃ anti-freeze measures)
- Fluid temperature: 0-60℃ (non-lubricated air required below 0℃)
- Protection grade: IP67 (dust/water resistant)
- Port alignment: ISO 5599-1 standard (compliant with CETOP RP52P)
- Weight: 780g ±5% (excluding accessories)
- Dimensions: 122mm(L) × 60mm(W) × 58mm(H) (manual override protrudes 15mm extra)
Industrial-grade directional control valve featuring pilot-assisted operation for low power consumption and high flow capacity. The hardened aluminum body with nickel-plated brass core ensures 10 million cycle durability. Includes manual override and LED status indicator. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line actuators
- Plastic injection molding machine clamps
- CNC machine tool clamping systems
- Food processing pneumatic circuits (FDA-compliant grease option)
- High-cycle packaging equipment (e.g., carton sealers)
Installation protocol:
Mount with M5 mounting screws (35N·m torque max). Maintain 50mm clearance
below valve for manifold heat dissipation. Use shock absorbers in
vibration-prone environments. Lubricate every 5M cycles with ISO VG32 oil.
| Property | Property Value |
|---|---|
| sku | HD4V120EI |
| Standard Voltage | AC24V |
