Airtac HD4V Solenoid Valve HD4V120F
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120F Solenoid Valve Technical Details
- Model: HD4V120F
- Type: 5/2-way double solenoid pilot-operated (bi-stable)
- Port size: G1/2 (ISO 228/1 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Flow capacity: Cv 2.5 / Kv 2.8 (at 0.5 MPa)
- Response time: ≤15ms (open), ≤10ms (close)
- Weight: 550g ±5% (with connectors)
- Dimensions: 120mm(L) × 50mm(W) × 80mm(H)
- Seal materials: NBR standard (FKM optional)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 13mm (minimum engagement)
- Max operating frequency: 5Hz (with 80% duty cycle)
The HD4V120F features dual-coil latching control for energy-efficient operation in central pneumatic systems. Its optimized spool structure delivers 30% faster response than standard 4V series valves, with reinforced brass body resisting vibration up to 10G. Requires 5μm filtration and automatic drain maintenance for optimal performance.
- High-speed press machine clamping sequences
- Robotic welding station actuator control
- Bottle filling/palletizing systems
- CNC tool changers with position memory
- Electroplating line cylinder sequencing
Installation protocol:
Mount with vibration-damping brackets in horizontal orientation.
Maintain 20mm clearance below valve for condensate drainage.
Use M12×1.0 counterclockwise threaded connectors (included).
| Property | Property Value |
|---|---|
| sku | HD4V120F |
| Standard Voltage | DC12V |
